Elevating Cylinder Rod Manufacturing with
Advanced Friction Welding Machines
Rotary friction welding offers the best possible bond for hydraulic piston rods and cylinder applications, and consequently, has been widely adopted by the world’s leading OEM’s and cylinder manufacturing companies for this safety critical application. Manufacturers rely on rotary friction welding machines to make rods of machine-controlled quality at faster weld cycles. It’s also a greener process that doesn’t result in smoke, fumes, or gases.
Beyond those benefits, friction welding technology has shown that it can solve more manufacturers’ operational challenges, including rod-eye misalignments, extended pre- and post-welding processes, and overly wide tolerances. These erroneous qualities increase manufacturing costs and waste, lowering the bottom line.
Recognizing these concerns, the manufacturers consulted with MTI to engineer enhanced manufacturing processes with minimized human errors. In response, MTI implemented innovative friction welding solutions across three newly developed rotary friction welding machines to optimize hydraulic cylinder rod production.
How MTI Engineered the Next-Generation Cylinder Rod Rotary Friction Welding Machine
When cylinder rod manufacturing clients approached MTI, they identified the following key requirements:
1.
Quick-Change Tooling to reduce downtime between changeovers.
2.
G-Code Programming Language for integrated flash turning.
3.
Tighter Weld Tolerances for enhanced post weld quality.
At MTI, our Sales and Engineering teams worked closely with customers to develop innovative, customer-driven solutions that exceeded these initial requests. By leveraging our friction welding expertise, precision engineering, and advanced machine capabilities, we have designed a next-generation rotary friction welding machine that redefines efficiency and performance in cylinder rod manufacturing.
The following section details how MTI’s friction welding technology sets new industry standards.
Advanced Features & Benefits of Cylinder Rod Rotary Friction Welding Machine
Quick Change Tooling – Minimize Downtime, Maximize Productivity
Fulfilling one of our clients’ improvement requests, MTI has developed Quick Change Tooling. This feature streamlines production by reducing tooling change time to less than five minutes. This breakthrough is advantageous for manufacturers with smaller lot sizes that require frequent changeover. Fixture tooling is designed to be non-marking for pre-chromed rods to preserve surface integrity during clamping and welding.
Rod Eye Alignment – Eliminate Human Error for Precision Welding
Rod-eye misalignments lead to defects and production slowdowns. Automatic rod-eye alignment in cylinder rod friction welding machines eliminates manual alignment errors when loading the eye into the chuck. By reducing operator dependency, this feature improves manufacturing efficiency with consistent, high-quality welds, tighter tolerances, and reduced scrap rates. MTI’s solutions are engineered to chuck and weld both clevises and traditional rod eyes, supporting a wide range of part geometries.
CNC-Controlled Flash Turning – Seamless Integration with Industry-Standard Systems
The flash resulting from friction welding is excess, extruded material that in some applications needs to be removed. The flash is more difficult to remove when it cools down and can cause excessive wear and tear on tools. The robust 2-axis CNC-controlled flash turning improves the finished part quality. It is fully integrated with Siemens Sinumerik systems and industry-standard G-code programming to reduce training time and improve efficiency.
New HMI with CNC Screen Integration – Smarter, More Efficient Control
The HMI-integrated split screen allows for both the welder and CNC programs to be monitored in real time. This advanced feature reduces the risks of crashes, collisions, and scrapped parts, especially during post-welding processes. An on-screen simulation tests the tool path of the FTO program before an operation, ensuring precision and efficiency of flash removal.
Cell Automation – The Future of Cylinder Rod Friction Welding
The new machines are versatile. They can be operated manually, semi-automatically, or fully automatically. When operated through full automation, they have in-feed conveyors and RFID scanning to confirm part length and type before welding. For customers seeking full traceability, MTI’s cell automation supports optional part marking capabilities—such as pre-weld laser engraving for rod eyes—linking parts directly to weld graphs. This results in improved quality assurance and part tracking across production.
How MTI Can Help with Your Next
Cylinder Rod Welding Project
At MTI, we are honored to fulfill the requests of our cylinder rod manufacturers and exceed their expectations. Our innovation is driven by the needs of our clients, reflected by our latest cylinder rod rotary friction welding machines.
Through our contract friction welding services, we also answer the call for manufacturers facing overflow production or needing specialized welding solutions for the construction, agriculture, and mining industries.
Ready to elevate your manufacturing process? Contact MTI today to discuss how our friction welding expertise can help optimize your cylinder rod production.
